4-Taper B.B.

BB-SG75 SUPER CERAMIC(B.B.)

SG75 SUPER CERAMIC
Picture : BB-SG75 Super Ceramic Zoom : BB-SG75 Super Ceramic
Click to enlarge.
User's Manual

» Download (PDF File)

Specification
Highest grade model of BB-SG75 series
Axle Type : 4-TAPER (SG75)
Cup Thread : BC1.37 × 24T
Shell Width : 68mm
Ball Race : Super high quality polish
Bearing : Ceramic balls

*Non NJS.

*SG75 taper is a proprietary standard by Sugino, not compatible with other standards.

*Use either of Sugino axle bolts of 18mm below the head, ❶one provided with BB-SG75, ❷14BK or ❸CPB. If the bolt is not long enough, this can lead to breakdowns and serious accidents.

Lubricant
Sugino CERAMIC LUBE

BB-SG75 SUPER LAP / Standard(B.B.)

SG75
Picture : BB-SG75 Super Lap Zoom : BB-SG75 Super Lap Zoom : BB-SG75 Standard
Click to enlarge.
User's Manual

» Download (PDF File)

Specification
SUPER LAP is high grade model of BB-SG75 series.
Axle Type : 4-TAPER (SG75)
Cup Thread : BC1.37 × 24T
Shell Width : 68mm
Ball race : SUPER LAP = super high quality polish
  Standard = normal

*NJS approved.

*SG75 taper is a proprietary standard by Sugino, not compatible with other standards.

*Use either of Sugino axle bolts of 18mm below the head, ❶one provided with BB-SG75, ❷14BK or ❸CPB. If the bolt is not long enough, this can lead to breakdowns and serious accidents.

Lubricant
Sugino CERAMIC LUBE

Sugino CERAMIC LUBE

Picture : Sugino CERAMIC LUBE Zoom : Sugino CERAMIC LUBE Zoom : Lubricate
Click to enlarge.
User's Manual

» Download (PDF File)

Specification
Lube for cup & cone style bearings (loose ball and retainer)
Press Release

» Press Release 2020 0916 Download (PDF File)

TL-BBSG75 Guide ring

CBB-SG75(B.B.)

SG75
Picture : CBB-SG75 Zoom : CBB-SG75
Click to enlarge.
User's Manual

» Download (PDF File)

Specification
Cartridge BB model of BB-SG75 series.
Axle Type : 4-TAPER (SG 75)
Cup Thread : BC1.37 × 24T
Shell Width : 68mm
Cup Material : Aluminium alloy

*Non NJS

*SG75 taper is a proprietary standard by Sugino, not compatible with other standards.

*Axle bolts are sold separately. Use either of Sugino bolts of 18mm below the head, ❶14BK or ❷CPB. If the bolt is not long enough, this can lead to breakdowns and serious accidents.

Small Parts
BB Axle Bolt

CBBAL(B.B.)

SG Mighty
Picture : CBBAL Zoom : CBBAL
Click to enlarge.
User's Manual
Standard model

» Download (PDF File)

Italian model (ITA)

» Download (PDF File)

Specification
■Standard model
Axle Type : 4-TAPER (SG Mighty)
Axle Width : 103, 110, 113, 116mm
CUP Thread : BC1.37 x 24T
Shell Width : 68mm
Cup Material : Aluminum alloy

■Italian model (ITA)
Axle Type : 4-TAPER (SG Mighty)
Axle Width : 110mm
CUP Thread : M36 x 24T
Shell Width : 70mm
Cup Material : Aluminum alloy

*SG Mighty taper is a proprietary standard by Sugino, not compatible with other standards.
Small Parts
BB Axle Bolt

CBBF(B.B.)

SG Mighty
Picture : CBBF Zoom : CBBF
Click to enlarge.
User's Manual

» Download (PDF File)

Specification
Axle Type : 4-TAPER (SG Mighty)
Axle Width : 103, 110, 113, 119mm
CUP Thread : BC1.37 x 24T
Shell Width : 68mm
Cup Material : Steel
*SG Mighty taper is a proprietary standard by Sugino, not compatible with other standards.
Small Parts
BB Axle Bolt

TL-CBB

Picture : TL-CBB Zoom : TL-CBB Zoom : TL-CBB
Click to enlarge.
User's Manual

» Download (PDF File)

Compatible Products

CBB-SG75
CBBAL
CBBF
